Custom Sheet Metal Fabrication Parts Bending Riveting and Assembly service

Product Name: Sheet Metal Bending Riveting Parts

Product Model:

Bending capability:

Maximum Part Size: 3 m x 1.5m

Metal Bending Forces: up to 125 tons

Bending Line Length: up to 3000 mm

Bending Thickness: up to 60 mm

General Tolerances: ISO 2768-M.

Bend to edge/hole, single surface: +/- 0.254 mm (+/- 0.010 in.)

Bend Radius: Be equal to material thickness

Bend Angle: +/- 0.5°

Bending Cutting Area: up to 4000 mm

【Previous】 Next

Bomei Plastic Hardware Limited is a professional manufacturer of custom made sheet metal parts, providing solutions of laser cutting, punching, bending, riveting, welding and assembly services for sheet metal parts.

Bomei combine highly advanced metal bending machines with skilled technicians for accurate bending. Our capabilities are suitable for rapid prototyping and production.

We follow ISO 2768 standards for sheet metal bending services to ensure to offer customers excellent quality prototypes and production parts.

With different types of metal bending techniques available, we can achieves various shapes and geometries for customers' desired applications.

Materials Available:

Carbon steel: 1008/1010/1020/1045 etc.

Cold Glvanized Steel

Stainless steel: SUS202/301/303/303Cu/304/316/316L/431 etc.

Aluminum: Aluminum 5051/5052/5083/6061/6083/7075 etc

The surface finish:

1. Anodizing, Electroplating, Sand blasting, Bead Blasting, Powder Coating, Polishing, Brushing.

For the carbon steel and the low alloy steel parts;

2. Tumbling, hand dull polishing, mirror polishing, electrolytic polishing and passivation treatment for stainless steel parts;

3. Sandblasting(including glass bead blasting, corundum-sand blasting and quartz-sand blasting), polishing and anodizing for aluminum parts.

BUSINESS SCOPE:

·Processing Machinery Parts

·Auto /Moto Parts

·Construction hardware

·Digital cutting equipment enclosures

·Electronic enclosures/chassis/brackets

·Medical equipment sheet metal parts.

·Lighting Components

·Hardware Accessories

·Agricultural Machinery

·Home Appliances

·Furniture Hardware

Quality:

1.100% inspected before shipping for sample.

2. Sampling inspection as the customer's requirements for mass production.

Production Lead time:

1.3-5 days for sample.

2. Consult with customer for mass production, normally it is 10-30 days.
